STRAIGHT PIPE CLEANING
RPCH Rotary Cleaning for Straight Pipes
The RPCH family is our most versatile line of pipe cleaning tools, designed for the widest range of configurations. A variety of head choices allow for pulling ring connections, customized porting, and multiple jetting options. Different viscous fluid options give operators the ability to change the speed of rotation for hard or easy applications. Can be used with a wide range of centralizers and backout preventers for added safety.
FEATURES:
·Clean 4in.(100mm) pipes to 15ft(4.5m) diameter tanks with simple modifications
·Interchangeable heads allow the tool to be used on any type of pump
·Multiple head options to allow for flush mounted nozzles, extension arms, plugs, and pulling rings
·Simple nozzle changes allow operators to configure for many cleaning applications
·Easy to pair with other accessories for hands-free pipe cleaning
RPCH There are several head configurations for the RPCH. The correct head specification
Is based on pressure and flow of the pump and the required port size.
Extension Standard
Model | Pressure Range | Flow Range | Rotation Speed | Inlet Connection | Weight | Max Water Temperature |
RPCH-70 | 2-10k psi | 20-200gpm | 20-80 rpm(Slow Fluid) 50-200 (Fast Fluid) | 1 NPT | 4.2 kg | 70°C |
RPCH-100 | 2-15k psi | 12-100gpm | 20-80 rpm(Slow Fluid) 40-200 (Fast Fluid) | 3/4 NPT | 3.9 kg | 70°C |
RPCH-150 | 2-22k psi | 12-100gpm | 20-80 rpm(Slow Fluid) 40-200 (Fast Fluid) | M24 | 4.1 kg | 70°C |
RPCH-280 | 20-40k psi | 3.4-20gpm | 20-60 rpm(Slow Fluid) 90-250 (Fast Fluid) | 9/16 HP | 4.4 kg | 70°C |
RPCH HEAD SPECIFICATIONS
STANDARD HEAD | RPCH-P16 | RPCH-P12 | RPCH-M24 | RPCH-MP12 | RPCH-H9 |
DIAMETER | 3.5in 89mm | 3.0in 76mm | 3.0in 76mm | 3.0in 76mm | 3.0in 76mm |
NOZZLES | 6 | 6或7 | 6或7 | 6或7 | 6、7或8 |
HEAD WEIGHT | 2.2kg | 1.5kg | 1.5kg | 1.5kg | 1.5kg |
EXTENSION HEAD | |||||
DIAMETER | 3.5in 89mm | 3.5in 89mm | 3.5in 89mm | 3.5in 89mm | 3.5in 89mm |
EXTENSION PORT | 6×3/4 NPT | 6×1/2 NPT | 6×G12 | 6×G12 | 6×G9 |
HEAD WEIGHT | 4.6lb 2.1kg | 4.8lb 2.2kg | 4.5lb 2.0kg | 5.2lb 2.4kg | 5.8lb 2.6kg |
RPCH-P16
OFFSET | R60 | R35 | R20 | R12 | |
PRESSURE | 10k psi 700bar | 49-95l/m | 83-150l/m | 150-240l/m | 250-380l/m |
15k psi 1000bar | 45-79l/m | 83-150l/m | 150-240l/m | 250-380l/m |
RPCH-P12
OFFSET | R20 | R12 | R09 | |
PRESSURE | 10k psi 700bar | 190-320l/m | 320-450l/m | 570-760l/m |
PCH-M24
OFFSET | R60 | R35 | R20 | R12 | |
PRESSURE | 22k psi 1500bar | 138-57l/m | 57-91l/m | 291-150l/m | 150-230l/m |
RPCH-MP12
OFFSET | R60 | R35 | R20 | R12 | |
PRESSURE | 15k psi 1000bar | 45-79l/m | 83-150l/m | 150-240l/m | 250-380l/m |
22k psi 1500bar | 45-76l/m | 45-79l/m | 130-220l/m | 220-380l/m |
RPCH-H9
OFFSET | R70 | R40 | R25 | |
PRESSURE | 30k psi 2100bar | 15-25l/m | 24-45l/m | 41-76l/m |
35k psi 2400bar | 14-24l/m | 24-42l/m | 38-68l/m | |
40k psi 2800bar | 3-22l/m | 22-39l/m | 36-65l/m |
RPCH CENTRALIZERS
Centering Devices for Any Application
RP-070 SKID STYLE
Utilities interchangeable plastic runners which can effectively clean up to 12in.(305mm)diameter pipes and works with all RPCH models(Tools not included)
Skid Sizes (Diameter) | |
RP070-6 | 6in. 150mm |
RP070-8 | 8in. 200mm |
RP070-10 | 10in. 250mm |
RP070-12 | 12in. 300mm |
RP-288 CENTRALIZER
Designed for straight pipe runs only, these six-wheel centralizers feature an adjustable, scissor-style aluminum frame and tough plastic wheels. They are compatible with the entire RPCH line of rotary tools(Tools not included)
Centralizer Sizes(Diameter) | Weight | |
RP-288S | 16-21in. 230-460mm | 12lb 5.5kg |
RP-288M | 22-29in. 560-740mm | 13lb 5.9kg |
RP-288L | 30-37in. 770-940mm | 16lb 7.3kg |
CAGE-STYLE CENTRALIZER
We recommend using stainless steel centralizers when negotiating complex piping arrangements and removing built-up debris while maintaining jet rotation.
Model | FHL-300 | FHL500 |
Diameter | 12in. 300mm | 20in. 510mm |
Length | 20in. 510mm | 24in. 610mm |
Weight | 10lb 4.5kg | 11lb 5.0kg |
